Product parameters

Voltage/Power：110-127V 60Hz 1200W / 220-240V 50Hz 1600W
Product dimensions: 310*45*72mm
Product weight: 545g
Plate size: 104*23*6.5mm
High Speed BLDC motor, 110,000 RPM
PTC heater
Button (or switch) features: one wave switch, one temperature increase/decrease button, one blower switch button
Power on/off operation method: Turn the wave switch to the top to turn on the product; turn the wave switch to the bottom to turn off
360º swivel cord
2.5 meter cable

Product operation description

1. Power on: Turn on the power and wave the wave switch to the top to turn on the product, the power on/off indicator light is on, and the first gear light is on.
2. Temperature increase/decrease: Short press the temperature increase/decrease button; 1-2-3-light off (temperature off)
3. Blowing switch button: Short press the blowing switch button to start blowing a breeze, the blowing indicator light is on, and the upper and lower aluminum plates are put together to blow strong wind; short press the blowing switch button to turn off the blowing, and the blowing indicator light is off
4. Shut down: Turn the wave switch to the bottom to shut down the product, and all functions stop working Gear temperature setting: 0 gear – 1 gear – 2 gear – 3 gear；Actual temperature: 0 – 170℃-200℃-230℃
5. Automatically shut down after 30 minutes when not in use
